Flame Retardant High Flexibility Abrasion Resistant PET Braided Cable Sleeve for Wire Harness Protection

Flame Retardant High Flexibility Abrasion Resistant PET Braided Cable Sleeve for Wire Harness Protection

Nom De La Marque: None
Numéro De Modèle: 5mm5m
MOQ: 1
Prix: negotiable
Conditions De Paiement: LC, D/A, D/P, T/T, Western Union
Supply Ability: 500 000M par jour
Des informations détaillées
Lieu d'origine:
Jangsu Chine
Certification:
ISO9001
Matériel:
ANIMAL DE COMPAGNIE
Température de fonctionnement:
-50 à 150C
Inflammabilité:
Haute inflammabilité
Ignifuge:
Auto-extinguible
Respectueux de l'environnement:
Sans halogène, respectueux de l'environnement
Couleur:
Noir, violet, bleu, jaune, rouge, rose, gris, marron, blanc, etc.
Taille:
5 mm, 6 mm, 10 mm, 12 mm, 15 mm, 16 mm, 25 mm jusqu'à 65 mm, d'autres tailles peuvent être p
Performance:
Haute résistance extensible
Résistance à la traction:
Bonne élasticité et traction
Point de fusion:
250 °C
Flexibilité:
Excellente flexibilité, facile à plier ou à rayer
Détails d'emballage:
Carton
Capacité d'approvisionnement:
500 000M par jour
Mettre en évidence:

flame retardant PET cable sleeve

,

abrasion resistant braided cable sleeve

,

high flexibility wire harness protector

Description du produit
UL94 High Flexible PET Braided Cable Sleeve
Product Overview

PET braided expandable sleeving, also known as PET braided mesh tube or snake skin tube, is woven from high-tenacity eco-friendly PET monofilament. This versatile solution is widely used for wire harness protection, management, and finishing, offering excellent flexibility, abrasion resistance, and heat dissipation capabilities.

Material & Construction
Material
High-tenacity eco-friendly PET polyester monofilament
Structure
Open braided construction with high elasticity
Expansion Ratio
Up to 1.5 times of original diameter
Technical Specifications
Operating Temperature
-50°C to 150°C
Melting Point
240±10°C
Flammability Rating
UL94 V-2, VW-1
Environmental Compliance
RoHS, Halogen-free
Key Features
  • Highly flexible and expandable
  • Abrasion-resistant construction
  • Flame-retardant properties
  • Breathable design for heat dissipation
  • Anti-aging and chemical-resistant
Available Specifications

Flat Widths: 3mm, 6mm, 8mm, 10mm, 12mm, 16mm, 20mm - 76mm

Standard Colors: Black, white, gray, red, blue, yellow, transparent

Applications
Electronics & Computers
Power cords, internal wiring, HDMI/USB/network cables, server equipment
Automotive & Rail
Engine harnesses, interior wiring, EV high voltage cables, charging pipes
Home Appliances
Air conditioners, refrigerators, washing machines, TVs, ovens
Industrial Equipment
Robots, automation machines, control cabinets, medical devices
Communication
Base stations, fiber jumpers, data center cables, optical equipment
Other Industries
Aerospace, marine wiring, audio engineering, stage lighting
